Scorpion A-3017 PNP Combo (4s)

249,99 €
Impuestos incluidos
Cantidad:

Size Chart
x
Size Chart

Measuring Tips to Assure The Best Fit

  • Measure your back size – wrap the measuring tape snugly around your ribcage, just under your bust line 1, keeping it horizontal. This will give you your band size.
  • Then measure around the fullest part of your bust 2 , again keeping the tape horizontal.
  • To determine the size of pants, measure the girth of the waist 3 and hips 4
  • The following charts will help you match the designer’s size scheme for this product (indicated in the dropdown) to your usual size

size guide visible to all products

UKUSAEUBUSTWaistHips
XS 8 4 34 31/32 23/24 33/34
S 10 6 36 33/34 25/26 35/36
M 12 8 38 35/36 27/28 37/38
L 12 8 38 35/36 27/28 37/38
XL 10 6 36 33/34 25/26 35/36

This specific A-3017 PNP Combo (4s), is designed for 4s powered 48" Acrobatic Airplanes, and UAV's requiring up to 962w of power with 3.5kg+ of thrust. It comes with our A-3017-920kv motor, pre programmed and pre-soldered Tribunus 06-80A ESC and a custom Scorpion Gold Metallic painted 13x6 propeller. This PNP combo is sure to give you the power you need, with the efficiency you want, all while making your airplane standout from the crowd

48" Acrobatic Weight Range (920kv) - : 1.3kg - 2.18kg (46oz - 77oz)

Sport / UAV (single engine) Weight Range (920kv) - : 3.0kg - 6.04kg (106oz - 213oz)

Recommended Battery Size - : 4s (14.8v) 2200-2800mah Lipo

Included in the Box

1 x Scorpion A-3017-920kv
1 x Tribunus 06-80A ESC SBEC (pre soldered w/ XT60)
1 x Scorpion 13x6 Metallic Gold Painted Prop
1 x Scorpion M Lock Strap
3 x Scorpion Stickers
16 x 3x10x1mm thrust spacing washers
4 x M3x10 moutning screws
4 x M3x16 mounting screws

Specifications

MOTOR :
Motor Kv 920 RPM / Volt
Weight (including mount + accessories) 154g (5.43 oz)
Motor Body Dimensions 36.60 mm x 36.5mm (1.44" x 1.44")
External Shaft Diameter 5.98mm
Continuous Current 45A
Continuous Power 665 Watts
Peak Current 65A
Peak Power 962 Watts
Max Rated Lipo Cell** 4s
No. of Stator Arms 12

ESC :
Max Continuous Current 80 Amps
Peak Current 100Amps
Operating Voltage Range 11-26.1 Volts
BEC Output voltage: 5.1V to 7.1V adjustable.
Max Continuous BEC Output 8 Amps @ 7.1 V
Max BEC Output 12A pules
Size 47.1 x 31 x 20 mm (1.85 x 1.22 x 0.79 in)
Weight (Without Connectors) 56g (1.98 oz)
Drive frequency 8kHz - 32kHz

A_3017_PNP_6s
