Brain2+Bluetooth flybarless

185,00 €
Impuestos incluidos
Cantidad:

Size Chart
x
Size Chart

Measuring Tips to Assure The Best Fit

  • Measure your back size – wrap the measuring tape snugly around your ribcage, just under your bust line 1, keeping it horizontal. This will give you your band size.
  • Then measure around the fullest part of your bust 2 , again keeping the tape horizontal.
  • To determine the size of pants, measure the girth of the waist 3 and hips 4
  • The following charts will help you match the designer’s size scheme for this product (indicated in the dropdown) to your usual size

size guide visible to all products

UKUSAEUBUSTWaistHips
XS 8 4 34 31/32 23/24 33/34
S 10 6 36 33/34 25/26 35/36
M 12 8 38 35/36 27/28 37/38
L 12 8 38 35/36 27/28 37/38
XL 10 6 36 33/34 25/26 35/36

BRAIN2 +BT SPECIFICATIONS:
Size (width x length x height):
29,6 x 36,8 x 14,2 mm
Weight:
15,3 g
13 Connections:
9 Servo type three pole male JR/Futaba connectors, with 11 signals connections (7 input and/or 7 output) and 8 servo power bus connections
1 On board micro USB connector capable to power internally the Unit
1 Wireless connection (Bluetooth)
2 SAT three pole JST connectors with 3,3V output (2 input and/or 2 output)
Serial input for every receiver Brand:
Spektrum:  Bidirectional SRXL (with telemetry) / Unidirectional SRXL / DSM2 22mS / DSM2 11mS / DSMX 11mS / PPM / Remote RX
Futaba:       S.Bus2 (with telemetry) / S.Bus / PPM
Jeti:              EX-BUS (with telemetry) / UDI / PPM+ / PPM-
Graupner:  SUMD (with telemetry) / SUMO
Multiplex:   SRXL + MSB (with telemetry)
FrSky:          S.Bus + Smart.Port (with telemetry) / S.Bus
JR:                X-Bus B
Hitec:          S.Bus
Telemetry input:
From ESC on electric models:
Castle Creation
Hobbywing
Align
Scorpion
Kontronik
YGE
From Temperature sensors on Nitro / Gasser / Turbine models:
Jeti
Futaba
From RPM sensors
All sensor brand
Telemetry output:
Spektrum, Futaba, Jeti, Graupner, Multiplex, FrSky
Power input:
Between 4,5V to 10V with one or two (redundant) lines from BEC or 2S Li-Po (7.4V) or 2S Li-Ion (7.4V) or 2S Li-Fe (6.6V) or 5/6/7 NiCd -NiMh
Outputs:
6 full programmable servos / ESC outputs. From 50 to 560Hz
Auto Diagnosis at each power on:
With result by LED flashes
With result by initial Swashplate movements
Diagnostic logs:
Up to 30 different parameters can be recorded during flights
Vibrations are also logged during flights
Up to 30 different type of Events are monitored and automatically logged during flights
Already included “on board”:
Status LED
Bluetooth
USB on board
Parameters setup / regulation:
Via apps in English, Deutsch, Francois,  Russian, Chinese, Italian (with the possibility to add, edit, share other languages):
Windows
MAC (with emulators)
Android
iOS
Via “Integrations” menu:
Spektrum
Jeti
Graupner
FrSky
Via dedicated transmitters channels (dials)
Up to other three dedicated channels other than tail gain
Swashplates:
90°
120°
135°
140°
Please download the latest software after purchase from “downloads section”.
Updates can be handled automatically by the software after first installation.
Visit the release notes under “info” menu of the software after each update.
